Wastewater Treatment & Recycling Solutions
Whether oily emulsions, process and wash waters, or contaminated rinse media – in disposal and recycling operations, composition and requirements often change from day to day. Depending on the task, our wastewater treatment and recycling solutions combine evaporation and ultrafiltration into a coherent system concept: from mechanical separation without chemicals to energy-efficient concentration with high distillate quality.
This reduces wastewater volumes and disposal costs, recovers water for reuse, and delivers stable, traceable results even with fluctuating waste streams.
ET MaXx ZLD
MAXIMUM CONCENTRATION OF INDUSTRIAL WASTEWATER STREAMS WITH ZERO LIQUID DISCHARGE
The ET MaXx ZLD extends MKR evaporation technology with an additional stage for further concentration.
After evaporation, the concentrate is further processed, minimizing the remaining water content and increasing the concentration of valuable substances. The distillate can be returned to the production process, while the residual volume is significantly reduced.
The result is a nearly closed water cycle in line with Zero Liquid Discharge (ZLD).
Module
Modules make wastewater treatment flexible: filtration, ultrafiltration, evaporation as well as pre- and post-treatment can be combined as required and expanded when needed. This keeps the system adaptable, even when wastewater streams and requirements change.
Accessories
Accessories meaningfully complement the system: pumps, tanks, sensors, as well as measuring and control technology can be selected and integrated to match. This ensures stable and efficient operation, even when media, volumes, and day-to-day conditions change flexibly and reliably.
Which technology is suitable for which type of wastewater?
|
MEDIUM / PROBLEM |
MKR Technology |
GOAL |
|---|---|---|
| Washing and degreasing baths | Ultrafiltration, tramp oil separation | Bath maintenance, extended service life |
| Oil-containing emulsions | Evaporator, ultrafiltration | Reduce wastewater volume |
| Rinse waters | Evaporator | Recover process water |
| Concentrates | ET MaXx ZLD | Further reduce residual volume |
| Metalworking fluids, oils, sludge, particles | Mobile suction and filtration carts | flexible media maintenance |
| Fluctuating industrial wastewater | Combination of pre-treatment, evaporator, and peripheral equipment | stable process solution |
When Is Filtration Sufficient, and When Is Evaporation Needed?
Not every industrial wastewater stream requires an evaporator system right away. If process media need to be reused and the main objective is to remove interfering substances, filtration or ultrafiltration is often sufficient.
Typical tasks of filtration include:
- removing particles, chips and sludge
- separating oils, greases and emulsions
- stabilizing washing and degreasing baths
- reducing bath changes
- keeping process media usable for longer
Evaporation becomes relevant when wastewater volumes need to be significantly reduced, complex industrial media must be treated or process water should be recovered. In this process, water is thermally separated from the wastewater. The result is a distillate, which can be reused or post-treated depending on its quality, and a concentrate, in which the retained substances are collected.
In many applications, the best solution is a combination of both technologies: filtration stabilizes the medium, while evaporation technology further reduces liquid residual streams. MKR evaluates the medium, contamination load, flow rate and required target quality to develop the right process solution — from filtration and ultrafiltration to evaporation and Zero Liquid Discharge concepts.
